Possibility of connection with any type of loader in the range
- Feeding both step by step with gripper or roller with variable speed and feedback stop
- Locking by means of two independent clamps and vertical pressure cylinder for fastening very close to the blade for a clean cut without burrs
- Automatic positioning of the clamps (on request)
- Management of the machine cycle by PLC, two controlled axes
- Sturdy vertical stroke head mounted on hardened and ground prismatic guides
- Automatic rotation of the head +/- 60 ° (on request)
- Head descent controlled by brushless motor with adjustable speed
- Blade motor with variable speed controlled by inverter, electronic blade guard
- Extraction pliers with optimization system of the last CNC-controlled cut (available on request on CNP model)
- Discharge system with two or more positions, adjustable position from panel.
- Teleservice
Our EUROMATIC model is a versatile single-head cutting-off machine, suitable for straight or angle cuts of great precision
| TECHNICAL SPECIFICATIONS | EUROMATIC – CNP | EUROMATIC – CNB | |
| Cutting capacity with head 370 | mm | Ø12 → Ø120 12×12 → 100×10020×15 → 120X80 | Ø12 → Ø120 12×12 → 100×10020×15 → 120X80 |
| Motor | KW | 4 | 4 |
| Blade diameter | mm | Ø370 (400 if request) | Ø370 (400 if request) |
| Blade speed | rpm | 20 → 130 controlled by inverter | 20 → 130 controlled by inverter |
| Blade feeding | Servo motor and ballscrew | Servo motor and ballscrew | |
| Bar feeding | Servo motor | Roll system high speed | |
| L. auto feeding | mm | 1500 mm with stroke repetition | |
| Degrees angle | ° | +/- 45° standard (+/- 60° optional) | +/- 45° standard (+/- 60° optional) |
| Cooling system | Cooling water/Spraymist | Cooling water/Spraymist | |
| Weight | kg | 2500 | 2500 |
| Tollerance | +/- 0.15 | +/- 0.15 |
Tutte le specifiche, dimensioni e caratteristiche di design mostrate in questo sito sono soggette a variazioni senza notifica da parte del costruttore.
